Lenovo ThinkPad X1 Carbon, Intel® Core™ i5, 35.6 cm (14"), 1920 x 1200 pixels, 8 GB, 256 GB, Windows 10 Pro

Lenovo ThinkPad X1 Carbon. Product type: Laptop, Form factor: Clamshell. Processor family: Intel® Core™ i5, Processor model: i5-1135G7. Display diagonal: 35.6 cm (14"), HD type: WUXGA, Display resolution: 1920 x 1200 pixels. Internal memory: 8 GB, Internal memory type: LPDDR4x-SDRAM. Total storage capacity: 256 GB, Storage media: SSD. On-board graphics card model: Intel Iris Xe Graphics. Operating system installed: Windows 10 Pro. Product colour: Black. Weight: 1.13 kg

• Laptop Clamshell Black
• Intel® Core™ i5 i5-1135G7
• 35.6 cm (14") WUXGA 1920 x 1200 pixels IPS LED backlight 16:10
• 8 GB LPDDR4x-SDRAM 4266 MHz
• 256 GB SSD
• Intel Iris Xe Graphics
• Wi-Fi 6 (802.11ax) Bluetooth 5.2
• Lithium Polymer (LiPo) 57 Wh 21.3 h 65 W
• Windows 10 Pro 64-bit

Features

Design
Colour name	Black, Paint
Product type	Laptop
Product colour	Black
Form factor	Clamshell
Housing material	Carbon fibre, Magnesium
Intel® vPro™ Platform Eligibility	No
Display
Display diagonal	35.6 cm (14')
Display resolution	1920 x 1200 pixels
Touchscreen	No
HD type	WUXGA
Panel type	IPS
LED backlight	Yes
Native aspect ratio	16:10
Anti-glare screen	Yes
Display brightness	400 cd/m²
RGB colour space	sRGB
Colour gamut	100%
Contrast ratio (typical)	1000:1
Processor
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	11th gen Intel® Core™ i5
Processor model	i5-1135G7
Processor cores	4
Processor boost frequency	4.2 GHz
Processor cache	8 MB
Processor cache type	Smart Cache
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-up	28 W
Configurable TDP-down	12 W
Configurable TDP-down frequency	0.9 GHz
Memory
Internal memory	8 GB
Internal memory type	LPDDR4x-SDRAM
Memory clock speed	4266 MHz
Memory form factor	On-board
Maximum internal memory	8 GB
Storage
Total storage capacity	256 GB
Storage media	SSD
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
SSD interface	NVMe, PCI Express 4.0
NVMe	Yes
SSD form factor	M.2
Optical drive type	No
Card reader integrated	No
Graphics
Discrete graphics card model	Not available
On-board graphics card	Yes
On-board GPU manufacturer	Intel
Discrete graphics card	No
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card model	Intel Iris Xe Graphics
Audio
Audio chip	Realtek ALC3306
Audio system	Dolby Atmos
Number of built-in speakers	4
Built-in microphone	Yes
Number of microphones	4
Camera
Front camera	Yes
Front camera resolution	1280 x 720 pixels
Front camera HD type	HD
Infrared (IR) camera	Yes
Privacy camera	Yes
Privacy type	Privacy shutter
Network
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Mobile network connection	No
Antenna type	2x2
WLAN controller model	Intel Wi-Fi 6 AX201
WLAN controller manufacturer	Intel
Bluetooth	Yes
Bluetooth version	5.2
Near Field Communication (NFC)	Yes
WWAN	Upgradable
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
HDMI ports quantity	1
HDMI version	2.0
Thunderbolt 4 ports quantity	2
Intel® Thunderbolt 4	Yes
Combo headphone/mic port	Yes
USB Type-C DisplayPort Alternate Mode	Yes
USB Sleep-and-Charge	Yes
USB Sleep-and-Charge ports	1
Performance
Motherboard chipset	Intel SoC
Keyboard
Pointing device	ThinkPad UltraNav
Keyboard language	UK English
Numeric keypad	No
Keyboard backlit	Yes
Spill-resistant keyboard	Yes
Software
Operating system architecture	64-bit
Operating system language	English
Operating system installed	Windows 10 Pro
Processor special features
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel Software Guard Extensions (Intel SGX)	No
Idle States	Yes
CPU configuration (max)	1
Embedded options available	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Battery
Battery technology	Lithium Polymer (LiPo)
Battery capacity	57 Wh
Battery life (max)	21.3 h
Fast charging	Yes
Power
AC adapter power	65 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
USB Power Delivery (USB PD)	Yes
Security
Cable lock slot	Yes
Cable lock slot type	Kensington
Fingerprint reader	Yes
Smart card reader	No
Windows Hello	Yes
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0
Password protection	Yes
Password protection type	Power on, SSD, Supervisor
Operational conditions
Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	5 - 43 °C
Operating relative humidity (H-H)	8 - 95%
Storage relative humidity (H-H)	5 - 95%
Certificates
Compliance certificates	RoHS
Sustainability
Sustainability certificates	ENERGY STAR, EPEAT Gold, TCO
Weight & dimensions
Width	315 mm
Depth	221.6 mm
Height	14.9 mm
Weight	1.13 kg
Logistics data
Harmonized System (HS) code	84713000
