Lenovo ThinkEdge SE10, 1.4 GHz, Intel Atom®, X6214RE, 4 GB, 256 GB, Windows 10 IoT Enterprise

Lenovo ThinkEdge SE10. Processor frequency: 1.4 GHz, Processor family: Intel Atom®, Processor model: X6214RE. Internal memory: 4 GB, Internal memory type: DDR4-SDRAM, Memory clock speed: 3200 MHz. Total storage capacity: 256 GB, Storage media: SSD, Card reader integrated. On-board graphics card model: Intel® UHD Graphics. Operating system installed: Windows 10 IoT Enterprise. Power supply: 65 W. Chassis type: Mini PC. Product type: Mini PC. Product colour: Black

• Mini PC Black 65 W
• Intel Atom® X6214RE 1.4 GHz Processor cores: 2
• 4 GB DDR4-SDRAM 3200 MHz 1 x 4 GB
• 256 GB SSD Card reader integrated
• Intel® UHD Graphics
• Ethernet LAN 2500 Mbit/s Wi-Fi 6 (802.11ax) Bluetooth 5.1
• Windows 10 IoT Enterprise

Features

Processor
Processor manufacturer	Intel
Processor family	Intel Atom®
Processor model	X6214RE
Processor cores	2
Processor threads	2
Processor frequency	1.4 GHz
Processor cache	1.5 MB
Processor cache type	L2
Memory
Internal memory	4 GB
Maximum internal memory	32 GB
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 4 GB
Memory slots	2x SO-DIMM
Memory clock speed	3200 MHz
Memory channels	Dual-channel
Storage
Total storage capacity	256 GB
Storage media	SSD
Optical drive type	No
Number of storage drives installed	1
Total SSDs capacity	256 GB
Number of SSDs installed	1
SSD capacity	256 GB
SSD interface	PCI Express 4.0
NVMe	Yes
SSD form factor	M.2
Card reader integrated	Yes
Graphics
Discrete graphics card	No
On-board graphics card	Yes
Discrete graphics card model	Not available
On-board GPU manufacturer	Intel
On-board graphics card model	Intel® UHD Graphics
Performance
Motherboard chipset	Intel SoC
Trusted Platform Module (TPM)	Yes
Product type	Mini PC
Network
Ethernet LAN	Yes
Ethernet LAN data rates	2500 Mbit/s
Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
Wi-Fi standards	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Antenna type	2x2
Bluetooth	Yes
Bluetooth version	5.1
Ports & interfaces
USB 2.0 ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	2
DisplayPorts quantity	1
DisplayPort version	1.4
HDMI ports quantity	1
HDMI version	1.4b
Ethernet LAN (RJ-45) ports	2
Line-out	Yes
Microphone in	Yes
Serial ports quantity	2
Power
Power supply	65 W
Design
Chassis type	Mini PC
Volume	0.8 L
Product colour	Black
Software
Operating system language	English
Operating system installed	Windows 10 IoT Enterprise
Display
Display included	No
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Weight & dimensions
Width	179 mm
Depth	135 mm
Height	34.5 mm
Weight	1.5 kg
Packaging content
Mouse included	No
Keyboard included	No
Certificates
Certification	ErP Lot 6/26 Low Halogen RoHS compliant REACH TED (ECO-declaration) WEEE Microsoft Azure IoT Edge certified AWS IoT Greengrass certified Ubuntu Core certified Ubuntu Server certified Red Hat Enterprise Linux certified
