Zyxel XGS2220-30HP, Managed, L3, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting

Zyxel XGS2220-30HP. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Installed SFP+ modules quantity: 4. MAC address table: 32000 entries, Switching capacity: 168 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af,.... Power over Ethernet (PoE). Rack mounting

• Managed L3 Web-based management
• Quality of Service (QoS) support
• Basic switching RJ-45 Ethernet ports quantity: 24
• 10G support
• MAC address table: 32000 entries Switching capacity: 168 Gbit/s
• Rack mounting
• AC Power supply included Power over Ethernet (PoE)

Features

Management features
Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
Cloud-managed	Yes
ARP inspection	Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
10G Ethernet (copper) ports quantity	2
Installed SFP+ modules quantity	4
Network
Networking standards	IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3an, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3x, IEEE 802.3z
10G support	Yes
Routing entries	64
Data transmission
Switching capacity	168 Gbit/s
Forwarding rate	125 Mpps
MAC address table	32000 entries
Static route	Yes
Jumbo frames support	Yes
Packet buffer memory	2 MB
Security
DHCP features	DHCP relay, DHCP server
IGMP snooping	Yes
IGMP proxy	Yes
Security algorithms	SNMP, SNMPv2, SNMPv3
BPDU filtering/protection	Yes
Authentication type	IEEE 802.1x, RADIUS, TACACS+
Multicast features
Multicast support	Yes
Multicast Listener Discovery (MLD) snooping	MLD v1/v2
Protocols
GARP VLAN Registration Protocol (GVRP)	Yes
Design
Rack mounting	Yes
Product colour	Black
LED indicators	Yes
Performance
Internal memory	1024 MB
Flash memory	64 MB
Mean time between failures (MTBF)	268.305 h
Power
Power source	AC
Power supply included	Yes
AC input voltage	100 - 240 V
Power consumption (max)	477 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	26
Total Power over Ethernet (PoE) budget	400 W
Operational conditions
Operating temperature (T-T)	-20 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 95%
Storage relative humidity (H-H)	10 - 90%
Heat dissipation	1626.57 BTU/h
Weight & dimensions
Width	441 mm
Depth	330 mm
Height	44 mm
Weight	4.35 kg
Packaging data
Package width	580 mm
Package depth	503 mm
Package height	95 mm
Package weight	5.77 kg
Certificates
Compliance certificates	RoHS, Federal Communications Commission (FCC), Low Voltage Directive (LVD), CE
